Crawler excavator FR245F
Crawler excavator FR245F
Crawler excavator LOVOL FR245F: Weichai + Linde powerplant, generation F cab, 1.2 m³ bucket and reinforced chassis.
Основные параметры
| Operating weight, kg | 23 700 |
| Travel speed, high/low, km/h | 5.1/3.0 |
| Platform rotation speed, rpm | 9.3 |
| Boom length, mm | 5 700 |
| Handle length, mm | 2 925 |
| Bucket digging force, kN | 148 |
| Handle digging force, kN | 106 |
| Max. traction force, kN | 228.1 |
| Overcome slope, % | 70 |
| Specific ground pressure, kPa | 53.2 |
| Bucket volume, m³ | 1.2 |
| Total length, mm | 9 760 |
| Support length, mm | 5 070 |
| Height to the top of the boom, mm | 3 322 |
| Upper platform width, mm | 2 980 |
| Height to top of cabin, mm | 3 100 |
| Ground clearance under counterweight, mm | 1 087 |
| Minimum ground clearance, mm | 462 |
| Superstructure turning radius, mm | 4 120 |
| Support length of track on the ground, mm | 3 640 |
| Chassis length, mm | 4 436 |
| Track width, mm | 2 380 |
| Chassis width including shoe width 600, mm | 2 980 |
| Track shoe width, mm | 600 |
| Shoe tooth height, mm | 26 |
| Counterweight height, mm | 2 466 |
| Tower width, mm | 2 700 |
| Distance from the center of rotation to the rear edge, mm | 3 050 |
| Max. cutting height, mm | 10 190 |
| Max. unloading height, mm | 7 260 |
| Maximum digging depth, mm | 6 510 |
| Max. digging depth (vertical wall height), mm | 5 980 |
| Max. excavation distance, mm | 9 660 |
| Max. digging radius, mm | 9 875 |
| Mini. turning radius of the working device, mm | 2 910 |
Двигатель
Двигатель
| Engine Manufacturer | WEICHAI |
| Engine model | WP7H |
| Number of cylinders | 6 |
| Air supply system | Turbocharging |
| Working volume, l | 6.8 |
| Max. torque, Nm at rpm | 1 000/1 300-1 500 |
| Engine power, kW | 160/2 000 |
Моторное масло
| Engine oil capacity, l | 25 |
Топливный бак
| Fuel tank capacity, l | 420 |
Платформа
| Platform type | The counterweight extends beyond the chassis |
Шасси
| Chassis type | X-shaped with fixed track |
Гусеница
| Track width, mm | 600 |
Опорный каток
| Number of road wheels (one side) | 9 |
Гидросистема
Гидронасос
| Hydraulic pump manufacturer | LINDE |
| Hydraulic pump model | HPR135D |
| Max. hydraulic pump flow, l/min | 423.2 |
| Hydraulic pump type | Axial piston variable pump*2+Gear pump |
Распределитель
| Distributor manufacturer | LINDE |
| Distributor model | OCV25 |
| Max. distributor flow, l/min | 300*2 |
Поворотный мотор
| Slewing Motor Manufacturer | HENGLI |
| Rotary motor model | HM5X130CHB |
| Rotary motor circuit pressure, MPa | 29.6 |
Бортовой редуктор
| Final drive manufacturer | LONKING |
| Final drive model | JXD165XCA |
| Final drive circuit pressure, MPa | 40 |
Давление ГПК
| GPC pressure, MPa | 34.3 |
Гидравлический бак
| Hydraulic tank capacity, l | 206 |
FR245F - LOVOL Heavy Industry crawler excavator for intensive excavation work, quarries and road construction. The model combines a powerful Weichai power unit, well-tuned Linde hydraulics and reinforced working equipment - from the bucket to the chassis.
The golden ratio of a hydraulic power unit
Engine Weichai WP7H + main pump Linde + main valve Linde - optimal power structure unit developed by Lovol.
Weichai has an industry laboratory for internal combustion engine reliability. PXE rotational molded plastic fuel tank - large volume, robust design, high fuel purity.
Main pump displacement is 8.3% larger than a number of competitors. Reverse steel shell design reduces friction and increases pump responsiveness by approximately 30%, overall efficiency is approximately 3%.
Vermicular graphite cast iron body: better vibration resistance and heat sink Withstood 3 million cycles on an ultra-high pressure test bench without cracking.
Generation F cabin
Modern silhouette, thoughtful ergonomics and improved visibility; more space for personal belongings and a more comfortable workplace.
Compliance with ROPS requirements. New interior and air ducts, larger storage areas, improved seats.
Air filter cover - with anti-slip panel and hidden fasteners. 8-inchtouch screen and one-step start button.
Three-stage fuel system in a compact unit. Three-section hood (middle part opens 75°) for access to the compressor. Air intake: maintenance interval increased from 500 to 1000 h.
Machine design
- Bucket Volume 1.2 m³for soil; optimized shape reduces resistance when scooping; wear-resistant materials of teeth and components.
- Boom and handle. Large cross-section, three-segment handle with variable profile and stiffening ribs; The axial seats and the bucket lever are reinforced.
- Chassis SHANTUI kit; modernized heat treatment of rollers and tracks - increased wear resistance.
Technical characteristics
A complete list of parameters grouped by sections is in the “Characteristics” tab on this page.
About the brand
Lovol Heavy Industry is a subsidiary of Weichai Holding Group. The company develops excavators, loaders, mining dump trucks and integrated solutions for construction.
Parameters and equipment may differ from the actual delivery; focus on the product and the contract.
